entire splicing process from splicing to heating without touching the 90S and only moving the fiber.
The fiber retention clamps support the automated operations. When the sheath clamps open automatically after splicing, the fiber
retention clamps gently hold the spliced fiber to keep it from flying out. The retention clamps release when the fiber is lifted
by the operator.
|Cladding diameter||80 to 150m|
|Coating diameter||100 to 1000m|
|Applicable fibers||SM MM DS NZ-DS EDF|
|Fiber cleaved length||8-22mm (standard)|
|Splicing mode||Auto & Manual|
|Average splice loss||0.02dB(SM) 0.01dB(MM) 0.04dB(DS) 0.04dB(NZDS)|
|Return loss||≥ 60dB|
|Environment conditions||Environment conditions: -25~+50C (operation temperature), 0~95%RH (hu|
|Protection sleeve length||20mm 40mm 60mm|
