Fiber Optic Splitter 3 Way Wavelength Division Multiplexer 20 nm Channel

China Fiber Optic Splitter 3 Way Wavelength Division Multiplexer 20 nm Channel supplier
Fiber Optic Splitter 3 Way Wavelength Division Multiplexer 20 nm Channel supplier Fiber Optic Splitter 3 Way Wavelength Division Multiplexer 20 nm Channel supplier Fiber Optic Splitter 3 Way Wavelength Division Multiplexer 20 nm Channel supplier Fiber Optic Splitter 3 Way Wavelength Division Multiplexer 20 nm Channel supplier

Large Image :  Fiber Optic Splitter 3 Way Wavelength Division Multiplexer 20 nm Channel

Product Details:

Place of Origin: CHINA
Brand Name: SINO
Certification: UL; SGS; ROHS
Model Number: SN - 016

Payment & Shipping Terms:

Minimum Order Quantity: 1 Piece MOQ On Request
Packaging Details: 10 or 20 PCS / Plastic Tray, 1 PC / Gift Box
Delivery Time: Delivery In 7 - 15 Business Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000 Pieces Per Monthly
Contact Now
Detailed Product Description
Pass Channel Wavelength Range (nm): 1500 ~ 1600 (or 1260~ 1360) Reflect Channel Wavelength (nm): 1260 ~ 1360 (or 1500~ 1600)
Directivity (dB): >50 Return Loss (dB): >50
Maximum Power Handling (mW): 500 Insertion Loss (dB): ≧30

Fiber Optic Splitter 3 Way Wavelength Division Multiplexer 20 nm Channel​

WDM system uses a multiplexer at the transmitter to join the signals together and a demultiplexer at the receiver to split them apart.It’s getting the multiple communication channels over one medium thus it can solve the shortage of fiber resources and reduce the cost of building and expanding a transmission network. This kind of wavelength division multiplexer(CWDM) modules are using epoxy-free thin film filter technology. With ultra low insertion loss, high isolation and wide passband, they are widly used for WDM system, optical access network and telecommunication. We offer different channel multiplexers,typical with 1ch, 2ch ,4ch, these will be a powerful solution for the market demand of cost-effective network system.

Features / Benefits:
► Wide and flat pass band;
► High isolation;
► Low insertion loss;
► High stability and reliability;
► Epoxy free on optical path;
► Telcordia GR-1221-CORE-1999 compliant.
Applications:
► Line monitoring;
► WDM network;
► Telecommunication;
► Fiber optical amplifier.

Performance Specifications:

Parameters
Center wavelength (nm)ITU, ITU+1
Passband (nm)ITU±6.5
Operating wavelength (nm)1460~1620 or 1260~1620
Channel Space (nm)20
Fiber TypeSMF-28e or customer specified
IL (dB)Transmission band0.6
Reflection band0.4
Isolation (dB)Transmission band30
Reflection band12
Ripple (dB)0.3
PDL (dB)0.1
PMD (ps)0.1
RL (dB)45
Directivity (dB)50
Maximum Optical Power (mw)500
Operating Temperature (℃)-40~85
Storage Temperature (℃)-40~85
Package Dimension (mm) (Φ×L)

Φ5.5*L34 250um Fiber
Φ5.5*L38 900um Fiber


Notes:

1. Specified without connectors.
2. Add an additional 0.2dB loss per connector.


Parameters1×21×41×81×161×321×641×128
Operating Wavelength (nm)1260~1650
Fiber TypeG657A1 or customer specified
Insertion Loss (dB)(P/S Grade)3.8/4.07.1/7.310.2/10.513.5/13.716.5/16.920.5/21.023.8/24.2
Loss Uniformity (dB)0.40.60.81.21.52.02.5
Polarization Dependent Loss(dB)0.20.20.20.250.30.350.4
Return Loss (dB) (P/S Grade)55/5055/5055/5055/5055/5055/5055/50
Directivity (dB)55555555555555
Wavelength Dependent Loss (dB)0.30.30.30.50.50.50.5
Temperature Stability (-40~85 ℃)(dB)0.40.40.40.50.50.50.5
Operating Temperature (℃)-40~85
Storage Temperature (℃)-40~85
Device Dimension (mm)40×4×440×4×440×4×450×4×450×7×460×12×4N/A
Module Dimension (mm)100×80×10100×80×10100×80×10120×80×18140×115×18140×115×18140×115×18
Mini-Module Dimension (mm)50×7×450×7×450×7×460×12×480×20×6100×40×6N/A


Mechanical Dimensions:

Fiber Optic Splitter 3 Way Wavelength Division Multiplexer 20 nm ChannelFiber Optic Splitter 3 Way Wavelength Division Multiplexer 20 nm Channel
Fiber Optic Splitter 3 Way Wavelength Division Multiplexer 20 nm ChannelFiber Optic Splitter 3 Way Wavelength Division Multiplexer 20 nm Channel

Ordering Information:


MWDM
 WavelengthFiberTypeFiberLengthConnector

35=1310pass
53=1550pass

1=BareFiber
2=900umloosetube

1=1m
2=2m

0=None
1=FC/APC
2=FC/PC
3=SC/APC
4=SC/PC
5=ST
6=LC
