Huawei HG8120C Fiberhome Onu Gpon Router 1GE 1FE VOIP 100 Original

Huawei HG8120C Fiberhome Onu Gpon Router 1GE 1FE VOIP 100 Original

Huawei HG8120C Fiberhome Onu Gpon Router 1GE 1FE VOIP 100 Original
Huawei HG8120C Fiberhome Onu Gpon Router 1GE 1FE VOIP 100 Original Huawei HG8120C Fiberhome Onu Gpon Router 1GE 1FE VOIP 100 Original

Large Image :  Huawei HG8120C Fiberhome Onu Gpon Router 1GE 1FE VOIP 100 Original Get Best Price

Product Details:

Place of Origin: China
Brand Name: HUAWEI
Certification: CE/ROSH/IOS9001
Model Number: HG8120C

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: stander packing
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 500sets
Detailed Product Description
Model Number: HG8120C Type: ONU, FTTx Solutions
Configuration: 2FE+1Pot Packing: 40pcs/ctn
G.W: 10kg/ctn Dimension: 90*82*25mm
High Light:

HG8120C Fiberhome Onu Gpon Router

,

1GE Fiberhome Onu Gpon Router

,

VOIP router fiberhome gpon onu

100% Original Huawei HG8120C 1GE+1FE+VOIP

Fiber to The Home Gpon Router

The Huawei HG8120C subscriber terminal is used as a client device for the construction of FTTH networks and is designed to provide broadband access services based on GPON technology in residential buildings and small offices. This terminal supports one PON connection at a distance of up to 20 km. Terminal EchoLife HG8310M is equipped with PON and Ethernet GE ports with auto-negotiation for high-speed forwarding.

Huawei HG8120C Fiberhome Onu Gpon Router 1GE 1FE VOIP 100 Original 0

Spec
The HG8120C an optical network terminal (ONT), is a high-end home Bridge in FTTH solution. By using the GPON technology, ultra-broadband access is provided for home and SOHO users.

The HG8120C: 2LAN+1POT

The HG8120C features high-performance forwarding capabilities to ensure excellent experience with VoIP, Internet and HD video services. Therefore, the HG8120C provides a perfect terminal solution and future-oriented service supporting capabilities for FTTH deployment.

The HG8120C Provide English firmware and EU, US, UK, AU Power adapter for your choice.
Features:
· GPON Interface: 1 * GPON interface (SC/UPC)
· Transmission Rate: 2.488Gbps downstream and 1.244Gbpsupstream
· LAN: 2*10/100 Base-T interfaces with RJ-45 connector
· VOIP: 1

Huawei HG8120C Fiberhome Onu Gpon Router 1GE 1FE VOIP 100 Original 1



Huawei HG8120C Fiberhome Onu Gpon Router 1GE 1FE VOIP 100 Original 2



Huawei GPON ONU HG8120C
Equipment Characteristics:
*1 x PON optical port (up to 2.5 Gb / s. G.984);
*1 x Gigabit Ethernet port;
*Type of optical connector SC / UPC;
*The ability to configure the device using the Web interface;
*Dimensions 200 x 140 x 35 mm;
*Process holes in the housing for wall mounting.

GPON features
Class B+ optical power budget

Authentication modes of SN, password, and SN+password
Multicast features
IGMP V2&V3 snooping
Dynamically controllable multicast
Security features
MAC address filtering
Anti-DoS


Device maintenance
Local service configuration, query, and software upgrade on the webpage
Automatic remote service provisioning, device management, and software upgrade through OMCI
Query of the information about the ONT optical transceiver
Intelligent monitoring
Reliable features
Dual system protection of the software
Ethernet features
VLAN filtering, VLAN transparent transmission
VLAN N:1 aggregation and VLAN 1:1 switch
